AEM 's High-Output Inductive Coils address the limitations of traditional inductive coils in high-performance applications. Unlike standard inductive coils, which provide long spark duration but struggle with delivering enough energy, AEM 's coils achieve both. This eliminates the need for a bulky Capacitive Discharge Ignition (CDI) system, which offers strong spark energy but with a shorter duration.
AEM 's coils deliver over 100mJ of spark energy and at least 40,000 volts, matching the capabilities of CDI systems. Additionally, they maintain a long spark duration at full power, unlike CDI systems that rely on smaller preliminary sparks to simulate a longer duration. This design makes AEM 's High-Output Inductive Coils suitable for engines with forced induction or nitrous injection.
Features:
• Available for vehicles with external igniters
• Massive Spark Energy, up to 118 mJ
• Incredibly long spark duration, up to 3.2mS
• Up to 41kV Output Voltage, without a CDI
• CDI-like spark energy without the need for a CDI
• Less expensive than aftermarket LS1 coils
• Robust construction allows them to be mounted almost anywhere
• Heavy-duty, weatherproof and shockproof design
• Can be installed directly to engine
!
